Stainless Steel braided Flex Connector With Extension Pipe For Car
Exhaust System
Products Details:
Stainless Steel Exhaust Braided Flex Connector With Extension Pipe
For Car Exhaust System
This universal replacement flex connector can withstand
temperatures in excess of 1100 degrees. - Stainless Steel Flex with
Aluminized Collars. - Standard Lining for Noise Reduction. - This
flex replaces a blowing or damaged flex on your exhaust. - This
flex can be used in your custom built system to reduce wear from
engine vibration and to make sure your pipe lines up with the
manifold correctly. - Easy clamp on installation (can be welded or
clamped).
- Flex lock construction provides leak-free connectors
- Flex lock construction provides a highly flexible tube design
- Manufactured from stainless steel for durability and corrosion
resistance
- An economical repair option without having to replace entire
exhaust assemblies
- Offered in a variety of styles and sizes for your installation
needs
Materials:
- Bellow materials: Stainless steel 304 (thickness 0.25-0.30mm)
- Braid and interlock: Stainless steel 304
- Collars (cap): Stainless steel or aluminized steel
- Nipple (extension tube): Stainless steel or aluminized steel
Specification:
| Inner Diameter (ID) | Flex length(L) | Overall length(L) |
| Inch | mm | Inch | mm | Inch | mm |
| 1-3/4" | 45 | 4" | 102 | 8" | 203 |
| 6" | 152 | 10" | 254 |
| 8" | 203 | 12" | 305 |
| 10" | 254 | 14" | 356 |
| 48 | 4" | 102 | 8" | 203 |
| 6" | 152 | 10" | 254 |
| 8" | 203 | 12" | 305 |
| 10" | 254 | 14" | 356 |
| 2" | 50.8 | 4" | 102 | 8" | 203 |
| 6" | 152 | 10" | 254 |
| 8" | 203 | 12" | 305 |
| 10" | 254 | 14" | 356 |
| 54 | 4" | 102 | 8" | 203 |
| 6" | 152 | 10" | 254 |
| 8" | 203 | 12" | 305 |
| 10 | 254 | 14" | 356 |
| 2-1/4" | 57.2 | 4" | 102 | 8" | 203 |
| 6" | 152 | 10" | 254 |
| 8" | 203 | 12" | 305 |
| 10" | 254 | 14" | 356 |
| 2-1/2" | 63.5 | 4" | 102 | 8" | 203 |
| 6" | 152 | 10" | 254 |
| 8" | 203 | 12" | 305 |
| 10" | 254 | 14" | 356 |
| 3" | 76.2 | 4" | 102 | 8" | 203 |
| 6" | 152 | 10" | 254 |
| 8" | 203 | 12" | 305 |
| 10" | 254 | 14" | 356 |
Customized dimension are also available.
Structures:
1) bellows + out braid
2) bellows + out braid + inner braid
3) bellows +out braid + inner braid + nipple (extension tube)
4) bellows + out braid + inter lock
5) bellows + out braid + inter lock + nipple (extension tube)
Others & as samples and drawings
Packaging and Delivery:
Fast delivery: in 5-8 days
Lead time for new production: No more than 30 days
Shipping terms: EXW FOB CIF
Packing methods: Plastic bag for each product, seaworthy carton and
woven bag with pallet or not.
We supplied exhaust flex pipe in hundreds of designs to fit
customer's requirement. Please kindly inform us your need. The best
offer will be supplied soon.
